Floor & Wall · Interchangeable Insert
Dseal FlexiGuard
FlexiGuard is a surface-mounted expansion joint profile with an interchangeable anti-slip TPE insert, accommodating up to 20 mm of movement across a 50 mm joint and rated for a wide -30 C to +120 C range.
Click image to zoom · 2D blueprint, 3D render & product photo
FlexiGuard is a surface-mounted floor and wall expansion joint profile fitted with an interchangeable TPE insert. The anti-slip insert and hard-wearing profile make it ideal for sports halls, gymnasiums and high-hygiene areas, and the system is available in floor-to-floor, wall-to-wall and corner versions to suit different building elements. Profiles are supplied in 3 m lengths with the insert on a 25 m roll.
FlexiGuard is built for a 50 mm joint width and accommodates up to 20 mm of movement, with a low 3 mm insert height that sits neatly into the finished surface. The replaceable TPE insert performs across a wide temperature range of -30 C to +120 C, so the joint stays serviceable in cold stores, sports facilities and warm interiors alike.
Key Benefits
- Anti-slip TPE insert improves safety in sports halls and wet areas
- Replaceable insert keeps high-traffic and high-hygiene floors looking new
- Surface-mounted profile installs over finished floors and walls
- Low 3 mm insert height sits flush for a clean, trip-free surface
- Wide -30 C to +120 C range suits cold stores and warm interiors
- Floor, wall and corner versions cover an entire space from one system
Applications
- Sports halls, gymnasiums and indoor stadiums
- Hospitals, laboratories and other high-hygiene areas
- Cold stores and temperature-controlled facilities
- Schools, universities and public circulation floors
- Wall-to-wall and corner joints in clad interiors
- Retail and commercial floors needing an anti-slip finish
Features & Construction
- Surface-mounted profile for a 50 mm joint width
- Accommodates up to 20 mm of movement
- Interchangeable anti-slip TPE insert at 3 mm height
- Profile supplied in 3 m lengths with insert on a 25 m roll
- Operating temperature range of -30 C to +120 C
- Floor-to-floor, wall-to-wall and corner versions available
Technical Specifications
| Joint width | 50 mm |
|---|---|
| Compensation | Up to 20 mm |
| Insert height | 3 mm |
| Profile length | 3 m (insert 25 m) |
| Temperature | -30°C to +120°C |
Installation Guide
- Clean and dry the finished surface along both sides of the 50 mm joint
- Position the surface-mounted profile centrally over the joint opening
- Mark and drill fixing points along each profile flange
- Anchor the profile securely to the substrate on both sides
- Cut the TPE insert to length from the 25 m roll
- Press the anti-slip TPE insert into the profile until it seats flush
- Repeat at corners and wall junctions using the matching versions
Maintenance & Care
FlexiGuard is easy to keep clean, which matters most in sports and high-hygiene settings: wash the anti-slip TPE insert with the surrounding floor and check that the surface-mounted profile stays firmly fixed. The low 3 mm insert height leaves no awkward recesses for dirt to collect.
When the insert eventually shows wear or loses grip, lift it out and press a fresh length from the 25 m roll into the same profile, with no need to disturb the fixed profile or surface. For replacement TPE inserts contact Dseal (Dhawan Associates) on +91 93109 97953.
FAQs
FlexiGuard — Frequently Asked Questions
What is FlexiGuard?
FlexiGuard is a surface-mounted expansion joint profile from Dseal with an interchangeable anti-slip TPE insert, designed for floors, walls and corners in sports and high-hygiene areas.
What material is the FlexiGuard insert?
The insert is TPE (thermoplastic elastomer), which gives an anti-slip, hard-wearing surface and stays flexible across a wide temperature range.
What joint width does FlexiGuard suit?
FlexiGuard is built for a 50 mm joint width, with the profile spanning the opening and the TPE insert running along the centre.
How much movement does FlexiGuard accommodate?
It accommodates up to 20 mm of movement across the 50 mm joint, absorbing thermal and structural shifts in the floor or wall.
Can FlexiGuard handle foot traffic and sports use?
Yes. The hard-wearing profile and anti-slip TPE insert are well suited to sports halls, gyms and busy public floors.
What temperature range does FlexiGuard work in?
The TPE insert performs from -30 C to +120 C, making FlexiGuard suitable for cold stores as well as warm interiors.
Is FlexiGuard waterproof?
The TPE insert resists surface water and is easy to wash down, but it is a surface movement profile; for fully sealed wet-area waterproofing discuss the substrate detail with Dseal.
How is FlexiGuard installed?
The surface-mounted profile is anchored over the finished joint on both sides, then the anti-slip TPE insert is pressed into place. Corner and wall versions install the same way.
How do I maintain FlexiGuard?
Wash the insert with the floor and check the profile fixings. Worn inserts are simply replaced from the 25 m roll within the existing profile.
What is the insert height?
The TPE insert sits at just 3 mm height, keeping the joint nearly flush with the finished surface.
What standards apply to FlexiGuard?
FlexiGuard is manufactured by Dseal under ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018 certified systems, with metal components to relevant extrusion standards.
How is FlexiGuard different from DriveFlex?
DriveFlex is a heavier carpark and ramp joint with a nitrile insert for a 50-65 mm gap, while FlexiGuard is a low-profile 50 mm surface joint with an anti-slip TPE insert for sports and hygiene areas.
Are wall and corner versions available?
Yes. FlexiGuard comes in floor-to-floor, wall-to-wall and corner versions so one system handles an entire space.
Are custom lengths available?
Yes. Profiles come in 3 m lengths and the insert on a 25 m roll, and Dseal (Dhawan Associates) can advise on longer runs and special details.
Who manufactures FlexiGuard?
FlexiGuard is made in India by Dhawan Associates under the Dseal brand.
Where can I buy FlexiGuard in India?
FlexiGuard is supplied across India directly by Dseal (Dhawan Associates). Call +91 93109 97953 for pricing and delivery.
